CD4 (MSVA-004R) & CO-0071-488 SignalStar Oligo-Antibody Pair #48809

Filter:
  • IHC
Immunohistochemistry Image 1: CD4 (MSVA-004R) & CO-0071-488 SignalStar™ Oligo-Antibody Pair
SignalStar™ multiplex immunohistochemical analysis of paraffin-embedded human squamous cell lung carcinoma using Ki-67 (8D5) & CO-0014-488 SignalStar™ Oligo-Antibody Pair #89034 (red), CD4 (MSVA-004R) CO-0071-647 SignalStar™ Oligo-Antibody Pair #93058 (cyan), TCF1/TCF7 (C63D9) & CO-0006-750 SignalStar™ Oligo-Antibody Pair #53114 (yellow), CD11b/ITGAM (D6X1N) & CO-0037-488 SignalStar™ Oligo-Antibody Pair #19619 (green), Pan-Keratin (C11) & CO-0003-594 SignalStar™ Oligo-Antibody Pair #30989 (magenta), Granzyme B (D6E9W) & CO-0009-647 SignalStar™ Oligo-Antibody Pair # 37369 (orange), and CD8α (D8A8Y) & CO-0004-750 SignalStar™ Oligo-Antibody Pair #62750 (white). All fluorophores have been assigned a pseudocolor, as indicated. Staining was performed on the BOND RX autostainer by Leica Biosystems.

Order Information # 48809

This product is not sold separately. Please see the SignalStar™ Multiplex IHC Panel Builder Tool for ordering information.

  • Product Includes
  • Related Products
Product IncludesVolumeReactivityIsotype
CD4 (MSVA-004R) Rabbit mAb (SignalStar™ Conjugate 0071) #6237250 µlHRabbit IgG
Complementary Oligo (CO-0071-488) #5178022 µl

Product Information

Product Usage Information

Application Dilution
SignalStar™ Leica Bond 1:50 - 1:200
SignalStar™ Manual 1:50 - 1:200

Storage

SignalStar conjugates are supplied in PBS (pH 7.2), less than 0.1% sodium azide, 2 mM EDTA, 0.05% Triton X-100, 2 mg/mL BSA, and 50% glycerol. Complementary oligos are supplied in nuclease-free water. Store at -20°C. Do not aliquot the antibody. All components in this kit are stable for at least 12 months when stored at the recommended temperature.

Product Description

SignalStar multiplex immunohistochemistry (IHC) is an advanced technology for labeling multiple proteins simultaneously in tissue samples using specific primary antibodies and fluorescent detection reagents. This technology offers accuracy and reliability in visualizing and analyzing protein expression while maintaining spatial context and tissue architecture.

SignalStar Oligo-Antibody Pairs are compatible with the SignalStar Multiplex IHC Buffer Kits for use in fluorescent multiplex imaging experiments. This product includes the oligo-conjugated antibodies and complementary oligos required for labeling your target protein on up to 10 slides. SignalStar Multiplex IHC Buffer Kits are required to amplify and image the target signal. Multiple oligo-antibody pairs can be conveniently combined into a multiplex panel using the SignalStar Multiplex IHC Panel Builder. SignalStar Multiplex IHC Kits & Reagents are not compatible with all of Cell Signaling Technology® products and protocols that are recommended for use in immunohistochemical assays.

Protocol

Specificity / Sensitivity

CD4 (MSVA-004R) Rabbit mAb (SignalStar™ Conjugate 0071) recognizes endogenous levels of total CD4 protein.

Species Reactivity:

Human

Source / Purification

Monoclonal antibody is produced by immunizing animals with recombinant human CD4 protein.

Background

Cluster of Differentiation 4 (CD4) is a glycoprotein composed of an amino-terminal extracellular domain (four domains: D1-D4 with Ig-like structures), a transmembrane part, and a short cytoplasmic tail. CD4 is expressed on the surface of T helper cells, regulatory T cells, monocytes, macrophages, and dendritic cells, and plays an important role in the development and activation of T cells. On T cells, CD4 is the co-receptor for the T cell receptor (TCR), and these two distinct structures recognize the Antigen–Major Histocompatibility Complex (MHC). Specifically, the D1 domain of CD4 interacts with the β2-domain of the MHC class II molecule. CD4 ensures specificity of the TCR–antigen interaction, prolongs the contact between the T cell and the antigen presenting cell, and recruits the tyrosine kinase Lck, which is essential for T cell activation (1).

Pathways

Explore pathways related to this product.


For Research Use Only. Not For Use In Diagnostic Procedures.
Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.
SignalStar is a registered trademark of Cell Signaling Technology, Inc.
U.S. Patent No. 10,781,477, foreign equivalents, and child patents deriving therefrom.
