Revision 5

#67836

Store at -20C

CST Logo
Orders:

877-616-CELL (2355)

[email protected]

Support:

877-678-TECH (8324)

3 Trask Lane | Danvers | Massachusetts | 01923 | USA

For Research Use Only. Not for Use in Diagnostic Procedures.

Applications:
W, IHC-Bond, IHC-P

Reactivity:
H Mk

Sensitivity:
Endogenous

MW (kDa):
89, 92

Source/Isotype:
Rabbit IgG

UniProt ID:
#P05362

Entrez-Gene Id:
3383

Product Usage Information

Application Dilution
Western Blotting 1:1000
IHC Leica Bond 1:100 - 1:400
Immunohistochemistry (Paraffin) 1:100 - 1:400

Storage

Supplied in 10 mM sodium HEPES (pH 7.5), 150 mM NaCl, 100 µg/ml BSA, 50% glycerol and less than 0.02% sodium azide. Store at –20°C. Do not aliquot the antibody.

For a carrier-free (BSA and azide free) version of this product see product #26104.

Specificity/Sensitivity

CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb recognizes endogenous levels of total CD54/ICAM-1 protein.

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic peptide corresponding to residues surrounding Pro410 of human CD54/ICAM-1 protein.

Background

Intercellular cell adhesion molecule-1 (CD54 or ICAM-1) is a cell surface glycoprotein that belongs to the immunoglobulin superfamily (IgSF) of adhesion molecules. CD54 is expressed at low levels in diverse cell types, and is induced by cytokines (TNF-α, interleukin-1) and bacterial lipopolysaccharide (1). Apical localization of CD54 on endothelial cells (or basolateral localization on epithelial cells) is a prerequisite for leukocyte trafficking through the endothelial (or epithelial) barrier (1). Apical expression of CD54 on epithelial cells mediates pathogen invasion as well as host defense, a pattern also observed in tumors (1). CD54 also functions as a co-stimulator on antigen presenting cells, binding to its receptor LFA-1 (leukocyte function-associated antigen-1) on the surface of T cells during antigen presentation (2). Cross-linking of CD54 or binding to its ligand triggers activation of Src family kinases and the Rho/ROCK pathway (3-7). Phosphorylation on Tyr485 of CD54 is required for its association with SHP-2 (5). SHP-2 seems essential for CD54-induced Src activation (7).

Species Reactivity

Species reactivity is determined by testing in at least one approved application (e.g., western blot).

Western Blot Buffer

IMPORTANT: For western blots, incubate membrane with diluted primary antibody in 5% w/v BSA, 1X TBS, 0.1% Tween® 20 at 4°C with gentle shaking, overnight.

Applications Key

W: Western Blotting IHC-Bond: IHC Leica Bond

Cross-Reactivity Key

H: Human M: Mouse R: Rat Hm: Hamster Mk: Monkey Vir: Virus Mi: Mink C: Chicken Dm: D. melanogaster X: Xenopus Z: Zebrafish B: Bovine Dg: Dog Pg: Pig Sc: S. cerevisiae Ce: C. elegans Hr: Horse GP: Guinea Pig Rab: Rabbit G: Goat All: All Species Expected

Trademarks and Patents

Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.

SignalStain is a registered trademark of Cell Signaling Technology, Inc.

XP is a registered trademark of Cell Signaling Technology, Inc.

All other trademarks are the property of their respective owners. Visit cellsignal.com/trademarks for more information.

限制使用

除非 CST 的合法授书代表以书面形式书行明确同意,否书以下条款适用于 CST、其关书方或分书商提供的书品。 任何书充本条款或与本条款不同的客书条款和条件,除非书 CST 的合法授书代表以书面形式书独接受, 否书均被拒书,并且无效。

专品专有“专供研究使用”的专专或专似的专专声明, 且未专得美国食品和专品管理局或其他外国或国内专管机专专专任何用途的批准、准专或专可。客专不得将任何专品用于任何专断或治专目的, 或以任何不符合专专声明的方式使用专品。CST 专售或专可的专品提供专作专最专用专的客专,且专用于研专用途。将专品用于专断、专防或治专目的, 或专专售(专独或作专专成)或其他商专目的而专专专品,均需要 CST 的专独专可。客专:(a) 不得专独或与其他材料专合向任何第三方出售、专可、 出借、捐专或以其他方式专专或提供任何专品,或使用专品制造任何商专专品,(b) 不得复制、修改、逆向工程、反专专、 反专专专品或以其他方式专专专专专品的基专专专或技专,或使用专品开专任何与 CST 的专品或服专专争的专品或服专, (c) 不得更改或专除专品上的任何商专、商品名称、徽专、专利或版专声明或专专,(d) 只能根据 CST 的专品专售条款和任何适用文档使用专品 , (e) 专遵守客专与专品一起使用的任何第三方专品或服专的任何专可、服专条款或专似专专

Orders: 877-616-CELL (2355) [email protected] Support: 877-678-TECH (8324) [email protected] Web: cellsignal.com
For Research Use Only. Not for Use in Diagnostic Procedures.

Revision 5

CST Logo
Western blot analysis of extracts from A549 cells, untreated (-) or treated with hTNF-α #8902 (10 ng/mL, 6 hr; +), using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb (upper) or β-Actin (D6A8) Rabbit mAb #8457 (lower).
Western Blotting Image 1: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded human urothelial carcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb performed on the Leica® BOND™ Rx.
Immunohistochemistry Image 1: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded human squamous cell lung carcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb performed on the Leica® BOND™ Rx.
Immunohistochemistry Image 2: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Orders: 877-616-CELL (2355) [email protected] Support: 877-678-TECH (8324) [email protected] Web: cellsignal.com
For Research Use Only. Not for Use in Diagnostic Procedures.

Revision 5

CST Logo
Immunohistochemical analysis of paraffin-embedded human prostate adenocarcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb performed on the Leica® BOND™ Rx.
Immunohistochemistry Image 3: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded human colon carcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb.
Immunohistochemistry Image 1: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded human renal cell carcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb.
Immunohistochemistry Image 2: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Orders: 877-616-CELL (2355) [email protected] Support: 877-678-TECH (8324) [email protected] Web: cellsignal.com
For Research Use Only. Not for Use in Diagnostic Procedures.

Revision 5

CST Logo
Immunohistochemical analysis of paraffin-embedded human endometrioid adenocarcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb.
Immunohistochemistry Image 3: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded human prostate carcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb.
Immunohistochemistry Image 4: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded human tonsil using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb.
Immunohistochemistry Image 5: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Orders: 877-616-CELL (2355) [email protected] Support: 877-678-TECH (8324) [email protected] Web: cellsignal.com
For Research Use Only. Not for Use in Diagnostic Procedures.

Revision 5

CST Logo
Immunohistochemical analysis of paraffin-embedded normal rhesus monkey spleen using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb.
Immunohistochemistry Image 6: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded human squamous cell lung carcinoma using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb (left) compared to concentration matched Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (right).
Immunohistochemistry Image 7: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
Immunohistochemical analysis of paraffin-embedded Ramos cell pellet (left, positive) or A549 cell pellet (right, negative) using CD54/ICAM-1 (E3Q9N) XP® Rabbit mAb.
Immunohistochemistry Image 8: CD54/ICAM-1 (E3Q9N) XP<sup>®</sup> Rabbit mAb
